EKKO EB13ES-145Li Lithium Straddle Stacker 2640 lb Cap., 145" Height, Side Shift

Name: EKKO EB13ES-145Li Lithium Straddle Stacker 2640 lb Cap., 145" Height, Side Shift
Brand: EKKO Lifts
SKU: EB13ES-145Li
Price: 7748.0 USD
Availability: InStock

SKU EB13ES-145Li

In Stock

$7,748.00 - $7,748.00

$7,748.00

$7,748.00 - $7,748.00

$7,748.00

Call/Text Us: 307-441-9566 Call Us

Live Chat With an Expert Live Chat

Description

The EKKO EB13ES-145Li is a lithium-powered straddle stacker that lifts 2,640 lb to 145 inches — roughly 12 feet — with the maneuverability of a pedestrian walkie and the reach of a much larger truck. Its straddle legs slide out to surround the load, so it handles closed-bottom and skid pallets that a standard stacker can't, and integrated side-shift lets the operator nudge a load left or right to line up with racking or a truck bed without repositioning the whole machine.

Adjustable forks (8.3 to 33.5 inches) and adjustable outrigger legs (45.7 to 59.1 inches) let one machine match pallet widths and load footprints that would otherwise need several. A 24V/50Ah lithium iron phosphate (LiFePO4) battery and an onboard 24V/15A charger let it recharge from a standard outlet during breaks — no separate charging room, no acid watering or gassing. The drivetrain pairs a 24V center drive motor with a 2.2 kW lift motor, both managed by a Curtis instrument controller.

It's built for indoor work — loading and unloading trucks, loading docks, stock rooms, manufacturing floors, and warehouse put-away. Polyurethane wheels and a 52.6-inch turning radius let it operate in aisles as narrow as 7 feet, and a steel, robotically welded chassis keeps it square under repeated load cycles. The EB13ES-145Li is part of the EKKO Lifts range of electric material handling equipment.

Features

Integrated side-shift — reposition the load laterally to line up with racking or truck beds without moving the stacker.
Lithium iron phosphate (LiFePO4) power — 24V/50Ah battery with an onboard 24V/15A charger for opportunity charging and no acid maintenance.
Adjustable forks and outrigger legs — forks adjust 8.3–33.5 inches and outrigger legs adjust 45.7–59.1 inches to fit varied pallet and load sizes.
Straddle-leg design — legs surround the load for stability and for handling closed-bottom and skid pallets.
Curtis instrument controller — manages a 24V center drive motor and a 2.2 kW lift motor.
Polyurethane drive wheels and an ergonomic tiller handle for smooth, level indoor floors.
Steel construction with robotic welding for repeatable joint strength.

What's Included

EB13ES-145Li straddle stacker
24V/50Ah lithium iron phosphate (LiFePO4) battery
Onboard 24V/15A charger

Specifications

EKKO EB13ES-145Li Specifications
Model	EB13ES-145Li
Load capacity	2,640 lb
Load center	24"
Maximum lift height	145"
Fork length	45.3"
Single fork width	4"
Overall fork width (adjustable)	8.3" – 33.5"
Lowered fork height	2.35"
Fixed leg length	36.5"
Adjustable outrigger legs	45.7" – 59.1"
Turning radius	52.6"
Overall length	70"
Maximum overall width	61"
Extended mast height	167"
Lowered mast height	95.7"
Battery	24V / 50Ah lithium iron phosphate (LiFePO4)
Onboard charger	24V / 15A
Lift motor	2.2 kW
Drive motor	0.75 kW (24V center drive)
Lift speed (laden / unladen)	92 / 136 mm/s
Lowering speed (laden / unladen)	112 / 98 mm/s
Travel speed (laden / unladen)	4.0 / 4.2 km/h
Controller	Curtis instrument controller
Drive wheels	Polyurethane
Service weight	1,495 lb
Warranty	3-year limited

Warranty

The EB13ES-145Li is backed by a 3-year limited warranty.

FAQ

How much can the EB13ES-145Li lift, and at what height?

It's rated for 2,640 lb at a 24-inch load center and lifts to a maximum height of 145 inches — about 12 feet.

How narrow an aisle can it work in?

With a 52.6-inch turning radius, it's designed to operate in aisles as narrow as 7 feet. Overall length is 70 inches and maximum overall width is 61 inches.

What battery and charger does it use?

A 24V/50Ah lithium iron phosphate (LiFePO4) battery powers the stacker, and a 24V/15A charger is built in — recharge from a standard outlet without a dedicated charging room or acid maintenance.

Does it side-shift?

Yes. Integrated side-shift moves the load laterally so the operator can align with racking or a truck bed without repositioning the machine.

Can the forks and legs adjust for different loads?

Forks adjust from 8.3 to 33.5 inches and the outrigger legs adjust from 45.7 to 59.1 inches.

What surfaces is it built for?

It runs on polyurethane wheels for smooth, level indoor floors — loading docks, stock rooms, manufacturing floors, and warehouse put-away.

How is it shipped?

It ships via freight. Contact our team to schedule delivery and confirm freight details for your location.

Documents

Manual and technical documents are available on request — contact sales@forkliftking.com or call +1 (307) 441-9566.
