EKKO EB13C-118 Full Powered Straddle Stacker 2800 lb Cap., 118" Height

Name: EKKO EB13C-118 Full Powered Straddle Stacker 2800 lb Cap., 118" Height
Brand: EKKO Lifts
SKU: EB13C-118
Price: 5268.0 USD
Availability: InStock

SKU EB13C-118

In Stock

$5,268.00 - $5,268.00

$5,268.00

$5,268.00 - $5,268.00

$5,268.00

Call/Text Us: 307-441-9566 Call Us

Live Chat With an Expert Live Chat

Description

The EKKO EB13C-118 is a full-powered electric straddle stacker rated for 2,800 lb at a 24-inch load center, with a raised fork height of 118 inches. Both lift and travel are motor-driven, so the operator walks behind on the tiller instead of pumping a hydraulic handle or pushing the load by hand. It is built for loading and unloading trucks, working loading docks, and moving stock across stock rooms, manufacturing floors, and warehouse aisles.

The straddle design carries the load between two adjustable legs rather than a counterweight, which keeps the overall length down to 73.4 inches and the turning radius to 56.1 inches — useful where a counterbalanced truck would not fit. Adjustable legs span 35.4 to 51.2 inches and the forks adjust from 8.6 to 32.1 inches, so the stacker straddles a range of load and pallet footprints. Forks lower to 2.56 inches to slide under low loads.

Power comes from a 24V/85Ah battery driving a 2.2 kW lift motor and a 0.75 kW DC travel motor, managed by a Curtis Instruments controller. A built-in 24V/10A charger is integrated into the unit, so it recharges on board without separate charging equipment. The chassis is steel, the load wheels are polyurethane for smooth indoor floors, and the tiller carries the drive and lift controls in one ergonomic head.

Features

Full-powered lift and travel — 2.2 kW lift motor and 0.75 kW DC drive motor; the operator steers from the tiller without manual pumping or pushing.
Curtis Instruments controller managing both lift and drive.
Onboard 24V/10A charger built into the unit — no separate charger to source or store.
Adjustable straddle legs (35.4–51.2 in) and adjustable forks (8.6–32.1 in) to fit different load and pallet widths.
118-inch raised fork height with the mast extending to 127.6 inches overall and collapsing to 85 inches for clearance.
Polyurethane load wheels sized for smooth concrete and finished warehouse floors.
Steel construction with an ergonomic tiller head consolidating the controls.

Specifications

EKKO EB13C-118 Specifications
Model	EB13C-118
Load capacity	2,800 lb
Load center distance	24"
Max. lifting height (raised fork)	118"
Extended mast height	127.6"
Lowered mast height	85"
Fork length	45.3"
Single fork width	4"
Fork adjustment width	8.6"–32.1"
Lowered fork height	2.56"
Adjustable leg width	35.4"–51.2"
Turning radius	56.1"
Overall length	73.4"
Max. overall width	61"
Battery	24V / 85Ah
Onboard charger	24V / 10A
Lift motor	2.2 kW
Drive motor	0.75 kW (DC)
Controller	Curtis Instruments
Load wheels	Polyurethane
Construction	Steel
Service weight	1,345 lb

FAQ

Is a battery charger included?

Yes. A 24V/10A charger is built into the unit, so it recharges on board without a separate external charger.

What does "full-powered" mean on this stacker?

Both functions are motor-driven: a 2.2 kW motor raises the forks and a 0.75 kW DC motor drives travel. The operator walks behind and steers from the tiller — there is no manual hydraulic pump and no pushing the loaded truck by hand.

How far do the legs and forks adjust?

The straddle legs adjust from 35.4 to 51.2 inches and the forks adjust from 8.6 to 32.1 inches, so the stacker can be set to straddle and lift a range of load and pallet widths.

Can it be used outdoors or on rough ground?

It is designed for smooth indoor surfaces — finished warehouse floors, loading docks, stock rooms, and manufacturing floors. The polyurethane load wheels are intended for level concrete, not uneven or outdoor terrain.

Documents

Manual and technical documents available on request — contact sales@forkliftking.com or call +1 (307) 441-9566.
